Description
| Engine Model | YNF40E1 | YNF40E2 | YNF40E3 | YNF40E4 |
|---|---|---|---|---|
| Engine Brand | Yunnei Power | Yunnei Power | Yunnei Power | Yunnei Power |
| Engine Series | Dewei YNF40 | Dewei YNF40 | Dewei YNF40 | Dewei YNF40 |
| Engine Manufacturer | Yunnei Power | Yunnei Power | Yunnei Power | Yunnei Power |
| Displacement | 3.92L | 3.92L | 3.92L | 3.92L |
| Emission Standard | National V | National V | National V | National V |
| Max Output Power | 125kW | 115kW | 105kW | 95kW |
| Rated Speed | 2600rpm | 2600rpm | 2600rpm | 2600rpm |
| Max Horsepower | 170hp | 156hp | 143hp | 129hp |
| Max Torque | 600N·m | 500N·m | 450N·m | 450N·m |
| Max Torque Speed | 1300 – 1900rpm | 1200 – 2000rpm | 1200 – 2200rpm | 1200 – 2200rpm |
| Full – load Minimum Fuel Consumption | Less than 198g/kW·h | Less than 198g/kW·h | Less than 198g/kW·h | Less than 198g/kW·h |
| Engine Type | 4 – valve, central injector, central camshaft, high – pressure common – rail fuel injection, rear – mounted gear chamber | 4 – valve, central injector, central camshaft, high – pressure common – rail fuel injection, rear – mounted gear chamber | 4 – valve, central injector, central camshaft, high – pressure common – rail fuel injection, rear – mounted gear chamber | 4 – valve, central injector, central camshaft, high – pressure common – rail fuel injection, rear – mounted gear chamber |
| Bore × Stroke | 102×120mm | 102×120mm | 102×120mm | 102×120mm |
| Valves per Cylinder | 4 | 4 | 4 | 4 |
| Intake Form | Turbocharged and intercooled | Turbocharged and intercooled | Turbocharged and intercooled | Turbocharged and intercooled |
| Cylinder Number | 4 | 4 | 4 | 4 |
| Fuel Type | Diesel | Diesel | Diesel | Diesel |
| Cylinder Arrangement | In – line | In – line | In – line | In – line |
